mosaic-G5 P6 RTK InCase PIN GNSS receiver board with USB C

mosaic-G5 P6 dual channel all-constellation multi-frequency top-performance high precision RTK GNSS receiver.

mosaic-G5 P6 high-reliability receiver tracks all Global Navigation Satellite System (GNSS) constellations and supports all current and future signals.

Achieve uncompromising accuracy for your most demanding projects with centimeter-level advanced RTK positioning and Galileo HAS corrections. Built for maximum responsiveness, the system delivers raw measurements with ultra-low latency and an exceptional 100 Hz update rate, while the dual-antenna configuration guarantees highly reliable heading data. To secure your operations in challenging RF environments, the receiver integrates AIM+ Premium—part of the advanced GNSS+ algorithm suite—providing superior protection against signal jamming and spoofing. All of this robust performance is delivered with industry-leading ultra-low power consumption, maximizing your equipment's autonomy in the field.

---

• Two antenna inputs with SMA or IPEX connector
• USB-C connector
• Two UART (3.3V)
• EVENTA, EVENTB external event inputs (3.3V)
• Two PPS outputs (3.3V)
• Two GPIO pins (3.3V)
• Time pulse LED: Green, Power LED: Purple, PVT LED (GPIO2): Red, RTK LED (GPIO1): Orange

• RxTools Control and Analysis Software
• Extensive visualization and evaluation features
• Dimensions 28x38 mm
• Weight: 10 gr.
• Fully assembled, tested and ready to use

WARNING: RX and EVENT inputs shall not be driven while input supply not present.

---
